Digital Airflow Sensor Probe
key sensor features
- sensor measures air velocity up to 6.7mp/h or 10.8km/h
- compact plug & play sensor.
- designed for indoor use.
- steel enclosure for non-power sensors or non-IP sensors. custom color & logo options available.
- industrial grade.
- 0u rack, DIN rail, magnetic or wall mountable sensor.
- plugs into the base unit.
- powered by the base unit.
- alerts via SNMP Traps, email or SMS.
- out of the box integration via Modbus TCP, SNMP.
- optional integration via MQTT for Industrial IoT applications1
.
1Requires FW 10 or higher
- compact plug & play sensor.
- designed for indoor use.
- steel enclosure for non-power sensors or non-IP sensors. custom color & logo options available.
- industrial grade.
- 0u rack, DIN rail, magnetic or wall mountable sensor.
- plugs into the base unit.
- powered by the base unit.
- alerts via SNMP Traps, email or SMS.
- out of the box integration via Modbus TCP, SNMP.
- optional integration via MQTT for Industrial IoT applications1
.1Requires FW 10 or higher
Most airflow sensors currently available for data centers or server rooms are analog sensors. They just report if airflow is present based on a mechanical trigger with some units allowing you to manually set the trigger level.
ServersCheck introduces one of the first standalone digital airflow sensors for data centers. The sensors measure airspeed in meters per second and report it as such to the base unit, the SensorGateway.
The digital airflow sensor probes can measure air speeds of up to 3m/s. This equivalent to air speeds of up to 6.7 mp/h or 10.8 km/h
Wired or Wireless
By default all sensors are connected to the SensorGateway (BASE-5) using a CAT6 or higher RJ45 cable.
Using the optional Wireless Hub & Node modules, any sensor can be turned into a wireless sensor.
Wireless Hub & Nodes
Using the optional Wireless Hub & Node modules, any sensor can be turned into a wireless sensor.
Wireless Hub & Nodes
Customize your sensor: color / enclosure / logo
custom color & logo
Not a fan of orange? Want the sensors to match the color of your mission critical infrastructure equipment? Want to reflect your corporate color? Want to feature your own logo?
custom enclosure
Need the sensors in a custom enclosure to fit your application? Together with our partners, we can help to design special enclosures to meet your requirements.
Contact us for pricing & more info
Custom Sensor Design
Do you need the sensor to be customized to meet specific requirements?
Do you need features added or changed?
Do you need different enclosures?
Do you need to combine multiple sensors?
Whatever your project is, let us know what you need. Together with our engineering team we can make the product that you need.
Contact us to discuss your project & requirements
Do you need features added or changed?
Do you need different enclosures?
Do you need to combine multiple sensors?
Whatever your project is, let us know what you need. Together with our engineering team we can make the product that you need.
Contact us to discuss your project & requirements
RS485 (Modbus RTU) version
Looking to integrate this sensor with your own gateway or industrial control system? For large accounts customers or OEMs we now do offer a RS-485 version of this sensor. It has the same specs as the normal sensor. However rather than talking to our base unit and then communicate over industrial protocols with 3rd party systems, this version allows for native integration bypassing our base units.
It offers the same features as our regular sensors but with following differences:
- RS485 Modbus RTU output
- individually addressable using dial switch
- 256 addresses available
- 12-24v DC input
Contact us for pricing & more info
It offers the same features as our regular sensors but with following differences:
- RS485 Modbus RTU output
- individually addressable using dial switch
- 256 addresses available
- 12-24v DC input
Contact us for pricing & more info
No PC or Software Required
The InfraSensing sensors connect to the base unit (BASE-5). The base unit is a standalone device that has its own IP address in your network. On its own it will monitor the sensor and trigger alerts via email, SNMP or optional SMS when needed.
There is no software or PC required for the sensors to run.
With our optional Monitoring Software you can centrally monitor sensors with trending and more. This is optional and not required.
